    BLG-05-EH M50/K12 Electro-Hydraulic Retractable RATED Bollards



    Combining elegance with top perimeter control, the BLG-05 Electro-Hydraulic M50/K12 certified rated bollard is the most robust barricade in the market. Sized 1000 mm (39”) in height and 270 mm (11”) in diameter, the K12 certified bollard features top-quality materials, and its hot-dip steel coating enhances sturdiness and durability.

    The electrically-operated K12 certified bollard is IP68 rated, so its drive unit is completely sealed and can operate even when completely immersed in water. The bollard comes with a broad range of power options, ranging from 120V to 380V. Its rising time is just 5 seconds, and its retracting time is 2 seconds.

    The bollards entail low operational and maintenance costs. They are ideal for cases where strong barricades are required, as the barrier can block a ~7 ton vehicle driving at 80kph (50mph). The bollards are M50 certified, and were double-tested for ASTM F2656 07-M50 and PAS68:2010 standards. Additionally, the BLG-05-EH’s versatile design enables individually operating each bollard, as well as using the system as a standalone product or integrated with other advanced access control technologies.

    Download product data sheet
    To download the file, please fill in your details:



      Product BLG-05-EH
      Height Above Road (H) 900mm/35" - 1000mm/39"
      Sleeve height (I) 1.84m/ 72"
      Bollard Internal Overlap ( O) 0.7m/27.5"
      Bollard Diameter (D) 270mm/ 11"
      Regular operation speed 5 sec
      Emergency fast operation (EFO) 3 sec
      Resistance "ASTM F2656 07-M50 P2 (single bollard tested)
      PAS68:2010 V/7500[N3]/80/90
      7.5 ton/ 80kph/ 15,000lbs/50mph
      Bollard continues to work after crash"
      IP Rate IP 68 can work completely submerged in water
      Operation temp -20+60 C/ -4 +140 F Heating unit is optional
      Finish Zinc/Paint/ Stainless/Polyurea
      Options Heating/ Led/ EFO
      Actuator Electrically driven - electric wire connections only (No hydraulic pipes)
      Limit switch Inductive UP DOWN limit switches
      Power 1.1 Kw three phase motor, power supply suits customer requirements
      Cycles per day 2700
      MCBF 1,500,000 cycles
