    BLG-02 Electro-Hydraulic M30/K4 Tested Bollard



    BLG-0-2 Electronic Hydraulic M30/K4 crash test certified bollard is one of our flagship products that offers the formidable strength and superb reliability making it the ideal solution for high-security sites as well as more public traffic control needs. This innovative and easy to use product measures 700mm (27.5”) in height and 219mm (8.6”) in diameter (also available in a 1,000mm / 39" option). The bollard boasts an IP68 rating which means that it is fully operational even when submerged in water. In addition, the HPU comes with a special drive unit housing a fully sealed oil compartment which although it works on a hydraulic system, it doesn’t need oil refill or top up.

    This electrically driven hydraulic bollard boasts a stainless steel coating to prevent corrosion, and also comes with optional LED lights for maximum visibility. An excavation depth of 1,400mm (55”) is required when installing the BLG-0-2 Electronic Hydraulic M30/K4 certified bollard. This product has been rigorously tested, at a facility based on ASTM M30/K4 standards, meaning that it can stop a vehicle weighing 6.8 tons driving at 48kph (30mph). Atop its outstanding features, the BLG-02-EH also boasts an elegant design and look which makes it resonate with the aesthetics of different environments.

    Download product data sheet
    To download the file, please fill in your details:



      Product BLG-02-EH
      Height Above Road (H) 700mm/27.5" or 1,000mm/39"
      Foundation depth 1.4m/55" or 1.7m/67"
      Sleeve height (I)1.2m/48" or 1.5m/59"
      Bollard Internal Overlap ( O)0.3m/ 11.8"
      Bollard Diameter (D)219mm/ 8.6"
      Regular Operation speed3 sec. raise / 1.5 sec. lower
      Emergency fast operation (EFO)1.2 sec
      Resistance Equivalent ASTM F2656 07-M30 Standards P1-Zero penetration
      6.8 ton/ 65kph/ 13,600lbs/30mph
      Bollard continue to work after crash
      IP RateIP 68 can work completely submerged in water
      Operation temp-20+60 C/ -4 +140 F Heating unit is optional
      FinishZinc/Paint/ Stainless/Polyurea
      OptionsHeaing/ Led/ EFO
      ActuatorElectrically driven - electric wire connections only (No hydraulic pipes)
      Limit switchInductive UP DOWN limit switches
      Power0.37 Kw three phase motor, power supply suits customer requirements
      Cycles per day2,700
      MCBF1,500,000 cycles
